R290 A+++ Multifunctional Heat Pumps Monoblock Heating/Cooling+Domestic Hot Water Solution with SG Ready 6KW/12KW/18KW
The Micoe OEM 2.0/2.5/3.0 Square Meters Solar Keymark Certification Flat Plate Portable Solar Termal Collector for heated water heating will be the solution this is certainly perfect water heating that is hot. With all the state certification from Solar Keymark, you are going to trust that this plate that is flat collector is made to produce performance this is certainly optimum.
Details
| R32 monobloc heat pump | |||||
| ECO FRIENDLY R290 | MMHP9D1 | MMHP15D1 | MMHP15D3 | MMHP22D1 | MMHP22D3 |
| A+++ Heating¹ | |||||
| Capacity (kW) | 2.92~9.1 | 4.3~15.2 | 4.3~15.2 | 7.24~21.9 | 7.24~21.9 |
| Input Power (kW) | 0.61~2.11 | 0.87~3.73 | 0.87~3.73 | 1.5~5.88 | 1.5~5.88 |
| Input Current (A) | 2.8~9.25 | 4.02~16.38 | 1.78~6.04 | 6.86~30.25 | 2.82~9.16 |
| A+++ Heating² | |||||
| Capacity (kW) | 2.99~8.16 | 4.25~14.55 | 4.25~14.55 | 6.36~19.45 | 6.36~19.45 |
| Input Power (kW) | 1.03~2.92 | 1.45~4.28 | 1.45~4.28 | 2.15~6.85 | 2.15~6.85 |
| Input Current (A) | 4.57~12.79 | 6.71~18.8 | 2.84~6.78 | 9.84~30.12 | 3.71~10.6 |
| SCOP (Water Temp. At 35℃) | 4.98 | 4.9 | 4.9 | 4.91 | 4.93 |
| SCOP (Water Temp. At 55℃) | 3.84 | 3.86 | 3.86 | 3.94 | 3.93 |
| Refrigerant Weight / GWP (kg) | R290/0.55/3 | R290/1.05/3 | R290/1.05/3 | R290/1.4/3 | R290/1.4/3 |
| CO² Equivalent | 0.0017t | 0.0027t | 0.0027t | 0.0042t | 0.0042t |
| Power Supply ( ) | 220-240/1/50 | 220-240/1/50 | 380-415/3/50 | 220-240/1/50 | 380-415/3/50 |
| Product Size (mm) | 1150*410*800 | 1285*455*930 | 1285*455*930 | 1285*455*1350 | 1285*455*1350 |
| Packed Size (mm) | 1300*485*950 | 1450*530*1050 | 1450*530*1050 | 1450*530*1470 | 1450*530*1470 |
| Product Weight (kg) | 110 | 134 | 134 | 195 | 195 |
| Packed Weight (kg) | 122 | 146 | 146 | 208 | 208 |
|
¹ Nominal Heating (Max) (A7/6℃,W30/35℃) A+++ ² Nominal Heating (Max) (A7/6℃,W47/55℃) A++ |
|||||
| R32 monobloc heat pump | |||||
| ECO FRIENDLY R290 | MMHP9D1 | MMHP15D1 | MMHP15D3 | MMHP22D1 | MMHP22D3 |
| A+++ Heating¹ | |||||
| Capacity (kW) | 2.92~9.1 | 4.3~15.2 | 4.3~15.2 | 7.24~21.9 | 7.24~21.9 |
| Input Power (kW) | 0.61~2.11 | 0.87~3.73 | 0.87~3.73 | 1.5~5.88 | 1.5~5.88 |
| Input Current (A) | 2.8~9.25 | 4.02~16.38 | 1.78~6.04 | 6.86~30.25 | 2.82~9.16 |
| A+++ Heating² | |||||
| Capacity (kW) | 2.99~8.16 | 4.25~14.55 | 4.25~14.55 | 6.36~19.45 | 6.36~19.45 |
| Input Power (kW) | 1.03~2.92 | 1.45~4.28 | 1.45~4.28 | 2.15~6.85 | 2.15~6.85 |
| Input Current (A) | 4.57~12.79 | 6.71~18.8 | 2.84~6.78 | 9.84~30.12 | 3.71~10.6 |
| SCOP (Water Temp. At 35℃) | 4.98 | 4.9 | 4.9 | 4.91 | 4.93 |
| SCOP (Water Temp. At 55℃) | 3.84 | 3.86 | 3.86 | 3.94 | 3.93 |
| Refrigerant Weight / GWP (kg) | R290/0.55/3 | R290/1.05/3 | R290/1.05/3 | R290/1.4/3 | R290/1.4/3 |
| CO² Equivalent | 0.0017t | 0.0027t | 0.0027t | 0.0042t | 0.0042t |
| Power Supply ( ) | 220-240/1/50 | 220-240/1/50 | 380-415/3/50 | 220-240/1/50 | 380-415/3/50 |
| Product Size (mm) | 1150*410*800 | 1285*455*930 | 1285*455*930 | 1285*455*1350 | 1285*455*1350 |
| Packed Size (mm) | 1300*485*950 | 1450*530*1050 | 1450*530*1050 | 1450*530*1470 | 1450*530*1470 |
| Product Weight (kg) | 110 | 134 | 134 | 195 | 195 |
| Packed Weight (kg) | 122 | 146 | 146 | 208 | 208 |
|
¹ Nominal Heating (Max) (A7/6℃,W30/35℃) A+++ ² Nominal Heating (Max) (A7/6℃,W47/55℃) A++ |
|||||
